家用電梯/別墅電梯 整梯功能表 Function list

功能名稱
Function

功能描述
Desprication

全集選
FCL-Full Collective Operation

在家用電梯/別墅電梯自動狀態或司機狀態，電梯在運行過程中，在響應轎內指令信號的同時，自動響應上行、下行時的召喚，任何層樓的乘客，都可通過登記上下召喚信號召喚電梯。
In automatic or attendant service,the elevator responds to the command signal in the car while automatically responding to the call when going up and down.Passengers on any floor can call the elevator by registering the up and down call signals.

檢修運行
Inspection Running

這是在檢修或調試家用電梯/別墅電梯時使用的操作功能。當符合運行條件時，按上/下行按鈕可使電梯以檢修速度點動向上向下運行。持續按下按鈕，電梯保持運行，松開按鈕即停止運行。
Up/down running in inspection speed.The elevator keep running by push on the button and stop when loosen the buton.

直接?？?/span>
Directly Parking

以距離為原則，自動運算生成從啟動到停車的平滑曲線，沒有爬行，家用電梯/別墅電梯直接?？吭谄綄游恢?。
With distance for the principle,automatic operation generated from start to stop a smooth curve,no creep,parked in the flat position directly.

自救平層運行
Auto rescue running

當家用電梯/別墅電梯處于非檢修狀態下，且未停在平層區，此時只要符合起動的安全要求，電梯將自動以慢速運行至近平層區，然后開門。
When the elevator is not in maintenance mode, and did not stap on the leveling area, when meeting the safety requirements, the elevator will automatically run at slow to a leveling area recently, and then open the door.

緊急救援運行
Emergency rescue running

對于人力操作提升裝有額定載重量的家用電梯/別墅電梯轎廂所需力大于400N的電梯驅動主機，設置緊急電動運行開關及操作，以替代手動盤車裝置。
When manual winding required over 400N, set up the emergency electric operation switch and operation, to replace manual winding.

電機參數自學習
Motor parameter self learning

家用電梯/別墅電梯系統在運行前對電機參數進行自學習。
Self learning the motor parameters when the system is first running.

井道參數自學習
Shaft parameters self learning

系統在快車運行前，需要對井道的參數進行自學習，包括每層的層高、強迫減速開關位置。
First normal running. the system need self learning about the shaft parameters, including each floor height. the position of deceleration switch.

自動返基站
Automatic returm to main landing

當超過設定時間，仍無內部指令和層站召喚時，電梯自動返回基站等候乘客。
When there is no order or calls, after a period of time the elevator will automatic return to the main landing.

關燈節電功能
FLP-Fan and light protection

當超過設定時間，仍無內部指令和層站召喚時，則自動切斷家用電梯/別墅電梯轎廂內照明、風扇等電源。
Elevator will enter energy saving mode under no operation, turn off the car light and fan automatically within present time after door closing.

前后門服務樓層設置
Front and back opening setting

家用電梯/別墅電梯系統可根據需要分別對前門和后門選擇服務樓層。
The system can set the front or back opening according to requirement.

服務樓層設置
Service floor setting

系統可根據需要靈活選擇關閉或激活某個或多個家用電梯/別墅電梯服務樓層及停站樓層。
The system can set the service floor according to requirement.

自動修正轎廂位置
Automatic correct the position of cabin

家用電梯/別墅電梯每次運行到端站位置，系統自動根據Diyi級強迫減速開關檢查和修正轎廂的位置信息，同時輔助特制的強迫減速減速度徹底消除沖頂和蹲底故障。
Elevator run to the end station every time, the system will check and correct the position of cabin automatically according to the first forced deceleration switch, and auxiliary special forced deceleration to eliminate the fault of overrunning

跳躍層樓顯示
Floor display

靈活定義廳外顯示控制板顯示內容，可以根據需要將顯示設置為非連續數據。
The flooro display can be discontinuous floor according to requirement.

反向自動消號
Automatic elimination of reverse command

當家用電梯/別墅電梯運行到終端層站或者運行方向變更時，將此前所登記的反向指令全部自動取消。
When the first or last landing is reached and elevator has to reverse, all commands originally registered will be eliminated.

開關門故障保護
Open and close fault protection

當檢測到開關門超過設定次數后仍未有效關門，系統停止開關門并輸出故障。
When open and close over setting times still not effective, the system will stop opening or closing and show faulty.

保持開門時間的分類設定
Opening keep time setting separately

家用電梯/別墅電梯系統根據設定的時間自動判別召喚開門、指令開門、門保護開門、延時開門等不同的保持開門時間。
The system will judge the opening keep time of calling opening, order opening, protection opening, delay opening through the setting time.

貫通門獨立控制Independent control of through opening

使用貫通門時，可分別單獨控制前后門。
Independent control of front or back door when through opening

強迫減速監測功能
Forced deceleration detection

家用電梯/別墅電梯系統在自動運行模式下，根據強迫減速開關位置、以及開關動作情況來監測、校正電梯轎廂的位置。
Under auto running, the system will detect and correct the position of cabin according to the position of forced deceleration switch and the operation situation of switch.

開門按鈕門區開門
Open button

家用電梯/別墅電梯停在門區時，可以在轎廂中按開門按鈕使電梯已經關閉或尚未關閉的門重新打開。
When elevator stop in door zone, can reopen the door through open button in cabin.

本層廳外開門
Open in landing

在無其它指令或外召的情況下，若轎廂?？吭谀骋粚诱荆?按下該層站外的召喚按鈕后，轎廂門自動打開。
When there is no call or order, the cabin stop in one floo, push the call box in landing, the door will be automatically open.

重復關門
Re-closing

家用電梯/別墅電梯持續關門一定時間后，若門鎖尚未閉合，則電梯自動開門，然后重復關門。
If the door lock not closed after the door keep closing for a period of time, the elevator will automatically open door, and re-closing.

滿載直駛
LNS-Load non stop

在自動無司機運行狀態，當轎內滿載時(一般為額定負載的80%) ,電梯不響應經過的廳外召喚信號。
When car is loaded to a predetermined percentage pf its capacity(normally it's 80%), it is considered"full". The car will bypass further hall calls.

超載保護
LWS-overload protection

保證家用電梯/別墅電梯轎廂運行時的速度在安全控制范圍內，以保證乘客的安全。
If the load exceeds the rate load, the sound signal will be given out by speaker, and "OVERLOAD" will be displayed, the car door will not close,the elevator will not start.

防打滑保護
Anti-slip protection

在非檢修狀態，家用電梯/別墅電梯運行過程中，如果連續運行了F9-02規定的時間(45秒)后，而且沒有平層開關動作過，系統就認為檢測到鋼絲繩打滑故障，所以就停止轎廂一切運行。
In the state of no maintenance, elevator running process, if the continuous operation over the stipulated time of the F9-02 (maximum 45 seconds)and there is no leveling switch action, the system think rope slipping fault is detected, so they stop all running of cabin.

接觸器觸點檢測保護Contactor detection protection

家用電梯/別墅電梯在運行或者停止?fàn)顟B(tài)下，檢測到接觸器的吸合狀態異常時，系統自動保護。
When elevator is running or stop, if the contactor is detected abnormal, the system will automatically protect.

電機過電流保護
Motor over-current protection

檢測到電機的電流大于Z大允許值時，家用電梯/別墅電梯系統自動保護。
The system will auto protect if detected the motor current over the max. allowed data.

電源過電壓保護
Motor over voltage protection

檢測到電源電壓大于Z大允許值時，系統自動保護。
The system will auto protect if detected the motor voltage over the max. allowed data.

電機過載保護
Motor over load protection

檢測到家用電梯/別墅電梯電機過載，系統自動保護。
The system will auto protect if detected the motor overload.

編碼器故障保護
Encoder faulty

全系統只使用一個高速編碼器來進行閉環矢量控制，如果該編碼器發生故障，家用電梯/別墅電梯系統自動停機，避免因無法得知編碼器故障引起的沖頂蹲底的故障。
Only one high-speed encoder for closed-loop vector control is used in system, if the encoder failure occurs, the system automatically shut down,prevent due to unknown encoder failure caused overrunning failure.

故障歷時記錄
Fault record

系統具有6個故障記錄，包括家用電梯/別墅電梯故障產生的時間與樓層等信息。
The system will records 6 faults, including the time and floor information of the fault.

稱重信號補償
Weighing signal compensation

系統可以在高端應用場合中使用稱重信號，對電梯的啟動進行補償。
System can use weighing signal in special application, to compensate the starting.

預轉矩設置
Pre-torque setting

系統可預先輸出與相應負載匹配的轉矩，以保證家用電梯/別墅電梯的舒適感。
System can be output in advance with the corresponding torque load matching, to ensure the comfort of the elevator.

門鎖短接檢測
Short detection of door lock

家用電梯/別墅電梯在自動運行模式下，每次開門到位均識別門鎖是否存在異常。
Under auto running, it will detect whether the door lock is abnormal during every door opening.

測試運行
Test running

測試運行包括新電梯的疲勞測試運行、禁止外召響應、禁止開關門、屏蔽端站限位開關、屏蔽超載信號等測試運行方法。
Including fatigue test run of the new lift, prohibit called response, prohibit open close the door, blocking end station limit switch,shielding overload signal etc. test methods.

一鍵求救功能
One key for help

通過操縱箱上通話按鈕，對控制柜對講主機進行呼叫，當無應答時，對講主機將自動向依次設置好的3組電話號碼(或手機)進行撥號，直到接通為止。
The communication button in COP will call the master phone in controller first, if no answer, it can dial to 3 setting numbers in turn, until it's connected.

停電應急自動平層Emergency autorescue device

當由于樓房停電導致運行中的轎廂不在門區而困人時，停電應急平層裝置就會啟動，驅動家用電梯/別墅電梯就近低速運行到門區開門放人。
when power off, the car is not in the leveling zone, the emergency auto rescue device will start, drive the car to the door zone and open to release he passengers.
